CUNI ELBOW
90 DEGREE ELBOW 1.5D
Material : Stainless steel fitting , Alloy Steel fitting, Carbon Steel fitting,Nickel alloy fitting
Production Range : 1/2''-72'' (DN10~DN1800)
Wall Thickness : SCH5S - XXS
Standard: ASME B16.9, ASMEB16.28,DIN2605,DIN2037, EN10253-2, EN10253-4, ГОСТ 17375-80
JIS2312,JIS2313,GB12459 ,GB13401, SH3408,SH3409,MSS-SP-75
LONG RADIUS ELBOWS, SHORT RADIUS ELBOW, CARBON STEEL ELBOW AND STAINLESS STEEL ELBOW
Butt-welded Pipe Elbow Production Range
Outside Diameter: Seamless Elbow ( 1/2″～24″) , ERW / Welded /Fabricated Elbow (1/2″～72″)
Wall Thickness: 3mm–40mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80,SCH120, SCH140, SCH160, XXS
Bending Radius: R=1.5D
Product’s Angle: 90°Long Radius Elbow
Production Grades: Stainless Steel, Alloy Steel, Duplex, Nickel Alloys, Low temperature Steel, Carbon Steel, Copper Nickle .
Pipe Elbow Material Grades
Stainless Steel Elbow:
ASTMA403WPGr.304,304L,304H,309,310,310S,316,316L,316Ti,317L,321, 321H,347, 347H,904L,08Х18Н10,08Х18Н10Т,12Х18Н10Т,20Х23Н13,20Х23Н, 08Х17Н14М2, 03Х17Н14М3 ,03Х17Н14М3 ,08Х17Н13М2Т ,10Х17Н13М2Т,08Х18Н10,03Х18Н11,20Х23Н18,08Х18Н12Б,08Х13,12Х17,06ХН28МДТ,08Х17Т,08Х21Н6М2Т, 08Х22Н6Т,10Х23Н18,12Х13
Carbon Steel Elbow: ASTMA 234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Low-Temperature Carbon Steel Elbow: ASTM A420 WPL3, A420 WPL6
Alloy Steel Elbow: ASTM/ ASME A/SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP 91
Duplex Steel Elbow: ASTMA 815, ASME SA 815 UNS NO S31803, S32205,S32750,904L
Nickel Alloy Elbow: ASTM/ ASME SB 336 UNS 2200 ( NICKEL 200 ), UNS 2201 (NICKEL 201 ), UNS 4400 (MONEL400 ), UNS 8020 ( ALLOY 20 / 20 CB 3, UNS 8825 INCONEL (825), UNS 6600 (INCONEL600 ), UNS 6601 ( INCONEL 601 ), UNS 6625 (INCONEL 625), UNS 10276 ( HASTELLOYC 276 )
